The 500kVA oil type three phase distribution transformer is manufactured by Rockwill ELectric Group in China. It complies with IEC standard for having high quality and long service life. We support customization for different voltage classes and capacities. We are professional transformer manufacturer and waiting for your cooperation.
Technical Data 6kV to 11kV Oil Type Distribution Transformer:
|
Rated Capacity(KVA)
|
Rated Voltage(KV)
|
Vector Group
|
Impedance(%)
|
No-load loss/
Load loss(KW)
|
No-load Current(%)
|
|
10
|
(HV)
11
10.5
10
6.3
6
(LV)
0.4
0.69
|
Yyn0, Dyn11
|
4
|
0.065/0.4
|
3.5
|
|
20
|
0.08/0.52
|
3.0
|
|
30
|
0.1/0.63(0.6)
|
2.3
|
|
50
|
0.13/0.91(0.87)
|
2.0
|
|
63
|
0.15/1.09(1.04)
|
1.9
|
|
80
|
0.18/1.31(1.25)
|
1.9
|
|
100
|
0.2/1.58(1.5)
|
1.8
|
|
125
|
0.24/1.89(1.8)
|
1.7
|
|
160
|
0.28/2.31(2.2)
|
1.6
|
|
200
|
0.34/2.73(2.6)
|
1.5
|
|
250
|
0.4/3.2(3.05)
|
1.4
|
|
315
|
0.48/3.83(3.65)
|
1.4
|
|
400
|
0.57/4.52(4.3)
|
1.3
|
|
500
|
0.68/5.41(5.15)
|
1.2
|
|
630
|
4.5
|
0.81/6.2
|
1.1
|
|
800
|
0.96/7.5
|
1.0
|
|
1000
|
1.15/10.3
|
1.0
|
|
1250
|
1.36/12.0
|
0.9
|
|
1600
|
1.64/14.5
|
0.8
|
|
2000
|
1.96/19.8
|
0.8
|
|
2500
|
2.31/23.0
|
0.7
|
